Magneto mount nut torque spec?
Posted: Wed Jul 12, 2023 11:34 pm
by seberggelet
Hello,
mounting my Eisenmann LA4 mags back onto the C85. Is there a torque spec for the two mounting nuts per mag?
Thanks,
Sebastian
Re: Magneto mount nut torque spec?
Posted: Thu Jul 13, 2023 8:16 am
by 6643
I think they are 5/16-24 thread. If so, 180-220 in-lbs.
If they are 5/16-18 then it's 155-175 in-lbs.
This information can be found in the C-series overhaul manual X-30010.
Re: Magneto mount nut torque spec?
Posted: Thu Jul 13, 2023 3:56 pm
by rominoff
Yes, agree with 6643, the overhaul manual list torques not specifically called out specifically elsewhere.
Re: Magneto mount nut torque spec?
Posted: Thu Jul 13, 2023 6:51 pm
by 6643
rominoff wrote: ↑Thu Jul 13, 2023 3:56 pm
agree with 6643
Re: Magneto mount nut torque spec?
Posted: Fri Jul 14, 2023 9:36 am
by 6183
Folks, this may be another one of John's accomplishments that he's keeping....shhhh
- John Cooper.jpg (17.34 KiB) Viewed 814 times
Re: Magneto mount nut torque spec?
Posted: Fri Jul 14, 2023 10:07 am
by 6643
6183 wrote: ↑Fri Jul 14, 2023 9:36 am
Folks, this may be another one of John's accomplishments that he's keeping....shhhh
Ha ha! Don't I wish! Still, BMW is putting my name on all those cars...
BTW, I was never the Ohio State football coach, and I also am not a famous British motorcycle racer, although I do own a 1974 Triumph Trident.
